Infrastructure
| S.No. | Name of the Machine | Machine Code | Make | Qty. | Capacity |
|---|---|---|---|---|---|
| 1 | Double Acting Hydraulic Press | HP | Fabricated | 3 | 30,50,100 TON |
| 2 | Power Pack | PP | Polyhtron | 3 | 80 Lits. |
| 3 | Oven | Oven | Fabricated | 2 | 30Kgs & 5Kgs |
| 4 | Lathe Light Duty | L | Anil, Dynamic | 8 | 4 1/2 ft |
| 5 | Lathe Heavy Duty | L | Dynamic | 1 | 5 1/4 ft |
| 6 | Lathe Heavy Duty | L | Accu Tech | 1 | 12 ft |
| 7 | Drilling Machine | D | Visam, ITCO | 2 | 2", 1/2'' |
| 8 | Tool grinder | T | Mgeeyem | 2 | 1 HP |
| 9 | Bench Polisher | B | Mgeeyem, ELMACO | 1 | 0.5, 1 HP |
| 10 | Hand Press | H | Fabricated | 1 | 12" X 12" |
| 11 | DRO | Milling Machine | M | 1 | |
| 12 | CNC | CNC | Ace Designers Ltd | 1 | Turning Dia - 320mm Turning Length - 400mm |
| 13 | CNC | CNC | Ace Designers Ltd | 1 | Turning Dia - 320mm Turning Length - 400mm |
| 14 | Air Compressor | C | Mastro | 1 | 200 lits. |
| S.No. | Description | Specification (Measuring Range) | CODE NO. / SERIAL No. | Quantity |
|---|---|---|---|---|
| 1 | Oven 01- Temperature Indicator | 0 to 500° C | SELEC - PID513 | 1 |
| 2 | Oven 02 - Temperature Indicator | 0 to 500° C | 1 | |
| 3 | Digital Caliper | 0-150 mm - Mitutoyo | 20856 | 1 |
| 4 | Digital Vernier Caliper | 0-150 mm - Baker | 1 | |
| 5 | Digital Caliper | 0-200 mm - Mitutoyo | 0013779, 0008132, 003586 | 3 |
| 6 | Digital Caliper | 0-300 mm - | 1 | |
| 7 | Digital Caliper | 0-300 mm - Mitutoyo | 30613 | 1 |
| 8 | Vernier Caliper | 0-300 mm - Mitutoyo | 14190114 | 1 |
| 9 | Vernier Caliper | 0-200 mm - Mitutoyo | 1 | |
| 10 | Vernier Caliper | 0-600 mm | 1 | |
| 11 | Dial vernier Caliper | 0-200 mm - Mitutoyo | 1 | |
| 12 | Vernier Height Gauge | 0-600 mm - Mitutoyo | 514-103 | 1 |
| 13 | Digital Height Gauge | 0-300 mm - Mitutoyo | 1 | |
| 14 | Thickness Gauge | 0.01 to 10 mm - Baker | TYPE - JO2 | 1 |
| 15 | Radius Gauge | 1 to 7 - Mitutoyo | 1 | |
| 16 | Radius Gauge | 7.5 to 15 - Mitutoyo | 1 | |
| 17 | Bore Gauge | 18-35 mm - Mitutoyo | 1 | |
| 18 | Bore Gauge | 35-60 mm - Mitutoyo | 1 | |
| 19 | Bore Gauge | 50-150 mm - Mitutoyo | 1 | |
| 20 | Analog Outside Micro Meter | 0-25 mm - Mitutoyo | 1 | |
| 21 | Analog Outside Micro Meter | 25-50 mm - Mitutoyo | 1 | |
| 22 | Outside Micro Meter | 50-150 mm - Mitutoyo | 1 | |
| 23 | Surface Table | 1000 x 630 x 100 mm | NS-SP-090 | 1 |
| 24 | Electronic Weighing Scale | 5 kg (Phoenix,Iota) | 3 | |
| 25 | Electronic Weighing Scale | 150 kg | 1 | |
| 26 | Duro Meter | Shore A | 14772 | 2 |
| 27 | Duro Meter | Shore D | 14707 | 1 |
| 28 | Pressure Gauge | 0 to100 kg/cm2 0 to 600 kg/cm2 0 to 400 kg/cm2 |
EN 837-1( WIKAI ) | 3 |
